Samsung SSD 870 QVO 1TB / 2TB / 4TB / 2.5" SATA3 QLC Internal SSD

Samsung SSD 870 QVO 1TB / 2TB / 4TB 2.5 SATA3 QLC

Specifications :

Model Code (Capacity) : 1TB / 2TB / 4TB
General Feature
APPLICATION : Client PCs
FORM FACTOR : 2.5 inch
INTERFACE : SATA 6 Gbps Interface (compatible with SATA 3 Gbps & 1.5 Gbps interfaces)
DIMENSION (WxHxD) : 100 X 69.85 X 6.8 (mm)
WEIGHT :
1TB: Apporx. 46.0 g
2TB: Apporx. 46.0 g
4TB: Apporx. 54.0 g


STORAGE MEMORY : Samsung V-NAND 4bit MLC
CONTROLLER : Samsung MKX Controller
CACHE MEMORY :
1TB: Samsung 1GB Low Power DDR4 SDRAM
2TB: Samsung 2GB Low Power DDR4 SDRAM
4TB: Samsung 4GB Low Power DDR4 SDRAM


Special Feature
TRIM SUPPORT : TRIM Supported
S.M.A.R.T SUPPORT : S.M.A.R.T Supported
GC (GARBAGE COLLECTION) : Auto Garbage Collection Algorithm
ENCRYPTION SUPPORT :
AES 256-bit Full Disk Encryption,
TCG/Opal V2.0,
Encrypted Drive (IEEE1667)

WWN SUPPORT : World Wide Name supported
DEVICE SLEEP MODE SUPPORT : Yes

Performance :
SEQUENTIAL READ : Up to 560 MB/s
SEQUENTIAL WRITE : Up to 530 MB/s

RANDOM READ (4KB, QD32) : Up to 98,000 IOPS
RANDOM WRITE (4KB, QD32) : Up to 88,000 IOPS

RANDOM READ (4KB, QD1 : Up to 11,000 IOPS
RANDOM WRITE (4KB, QD1) : Up to 35,000 IOPS

Environment
AVERAGE POWER CONSUMPTION (ACTIVE) :
1TB: 2.1 W / 2.2 W (Read/Write)
2TB: 2.1 W / 3.0 W (Read/Write)
4TB: 2.2 W / 3.2 W (Read/Write)


POWER CONSUMPTION (IDLE) :
1TB: 30 mW
2TB: 30 mW
4TB: 35 mW


POWER CONSUMPTION (DEVICE SLEEP :
1TB: 3 mW
2TB: 4 mW
4TB: 7 mW

ALLOWABLE VOLTAGE : 5V ± 5% Allowable voltage
RELIABILITY (MTBF) : 1.5 Million Hours Reliability
OPERATING TEMPERATURE : 0°C to 70°C
SHOCK : 1,500 G & 0.5 ms (Half sine)

Accessories
INSTALLATION KIT : N/A

Software MANAGEMENT KIT : Magician Software for SSD management

Warranty :
MZ 77Q1T0 (1 TB) : 3 Year or 360 TBW
MZ 77Q2T0 (2 TB) : 3 Year or 720 TBW
MZ 77Q4T0 (4 TB) : 3 Year or 1,440 TBW
